Advantech PCI-1753 96-Ch Digital I-O PCI Card
16865 INR/Unit
Product Details:
- I/O Cards Type 96-ch Digital I/O PCI Card
- Condition New
- Use Industrial
- OS Supported Yes
- Warranty Yes
- Click to View more
X
Advantech PCI-1753 96-Ch Digital I-O PCI Card Price And Quantity
- 1 Unit
- 16865 INR/Unit
Advantech PCI-1753 96-Ch Digital I-O PCI Card Product Specifications
- Yes
- New
- Industrial
- 96-ch Digital I/O PCI Card
- Yes
Advantech PCI-1753 96-Ch Digital I-O PCI Card Trade Information
- Cash in Advance (CID)
- 100 Unit Per Month
- 2-7 Days
- All India
Product Description
CIRCUIT BOARD, 96ch TTL Digital I/O Card
- Up to 192 (96 + 96) TTL digital I/O lines
- Emulates mode 0 of 8255 PPI
- Buffered circuits for higher driving capacity than 8255
- Multiple-source interrupt handling
- Interrupt output pin for simultaneously triggering external devices with the interrupt
- Output status read-back
- "Pattern match" and "Change of state" interrupt functions for critical I/O monitoring
- Keeps I/O setting and digital output values when hot system reset
The Advantech PCI-1753 96-Ch Digital I/O PCI Card is a high-performance input/output card designed for industrial use. With its 96 channels of digital I/O, this card is perfect for applications that require a large number of inputs and outputs. The card is compatible with a wide range of operating systems and is easy to install and configure. The typical power consumption of the card is 5V @ 400mA, while the operating temperature range is 0-60C (32-140F). The card is also designed to operate in environments with high humidity, with an operating humidity range of 5-95% RH. The cards compact size of 175 x 100 mm (6.9" x 3.9") makes it ideal for use in a variety of industrial applications.
| Typical Power Consumption | 5 V @ 400 mA |
| Operating Temperature | 0 60 DegreeC (32 140 DegreeF) |
| Operating Humidity | 5 95% RH |
| Color | Green |
| Dimensions | 175 x 100 mm (6.9" x 3.9") |
FAQs of Advantech PCI-1753 96-Ch Digital I-O PCI Card:
Q: What is the typical power consumption of the Advantech PCI-1753 card?
A: The typical power consumption of the card is 5V @ 400mA.
Q: What is the operating temperature range of the Advantech PCI-1753 card?
A: The operating temperature range of the card is 0-60C (32-140F).
Q: Is the Advantech PCI-1753 card compatible with all operating systems?
A: The card is compatible with a wide range of operating systems.
Q: What is the operating humidity range of the Advantech PCI-1753 card?
A: The card is designed to operate in environments with high humidity, with an operating humidity range of 5-95% RH.
Q: What is the size of the Advantech PCI-1753 card?
A: The card has a compact size of 175 x 100 mm (6.9" x 3.9"), making it ideal for use in a variety of industrial applications.
